- Place of Origin: Guangdong, China (Mainland)
- Brand Name: LIYI
- Model Number: LY-XJJD5
Detailed Product Description
| Charpy Impact Energy: | 1 J, 2 J,4 J,5 J | Impact Speed: | 2.9 M/s |
| Starting Angle: | 150° | Corner Radius Of Striking Edge: | (2.0±0.5)mm |
| Specimen Support Span: | 60mm,70mm,95mm | Included Angle Of Striking Edge: | (30±1)º |
| Corner Radius Of Vice: | (1.0±0.1)mm | Support Span: | 62 Mm |
| Accuracy: | ±0.1% | Tester: | Digital Charpy Izod Impact Test Machine |
| Pendulum Energy: | 1.0J、2.75J、5.5 J |
Intelligent Plastic Testing Equipment , Digital Charpy Izod Impact Test Machine
Introduction:
The digital charpy izod impact test machine is mainly used to measure the impact toughness of rigid
plastic, reinforced nylon, fiberglass, ceramics, cast stone, insulation materials and other non-metallic
materials. It is the ideal testing equipment in the chemical industry, scientific research
institutes, universities and quality testing departments.
Features:
1) It is a kind of intelligent digital testing machine using the microcomputer technology. It is advanced
that it can automatically correct the energy loss caused by friction and windage to modify the energy
chart, getting rid of the resistance effect. (The detection of the pendulum energy after specimen
fracture and the correction of energy loss are finished during the impact at once)
2) The test results of plastic digital charpy impact testing machine are electrically displayed to make the
reading more intuitive, improving the precision and accuracy of the impact machine.
3) The rotary encoder circular grating angle measurement technology is used by the instrument to
display the thrusting energy, impact strength, pre Yang angle, up angle, the average angle and the
energy loss corrected automatically, with the advantages of high accuracy ,good stability and a large
measure range.
4) The main technical parameters are strictly in conformity with the standards of ISO 179,GB/T 1043
and JB/T 8762.
Specifications:
Type | LY-XJJD5 | LY-XJJD50 |
Impact energy | 1 J, 2 J,4 J,5 J | 7.5 J,15 J,25 J,50 J |
Impact speed | 2.9 m/s | 3.8 m/s |
Starting angle | 150° | |
Corner radius of striking edge | (2.0±0.5)mm | |
Specimen support span | 60mm,70mm,95mm | |
Included angle of striking edge | (30±1)º | |
Corner radius of vice | (1.0±0.1)mm | |
Support span | 62 mm | |
Accuracy | ±0.1% | |
Mode: | LY-XB5.5 | LY-XB22 |
Impact speed: | 3.5m/s | |
Pendulum energy: | 1.0J,2.75J,5.5 J | 11J 22J |
Pendulum angle: | 150degree | |
Impact center distance: | 335mm | |
Accuracy: | ±0.1% | |
Resolution: | 1% | |
Distance between impact blade and clamp mouth | 22.0mm±0.2mm | |
Blade fillet radius | R=0.8mm±0.2mm | |
Energy loss: | 1.0J—2%；2.75J—1%；5.5J—0.5% | 11J,22J—0.5% |
Specimen type: | Best type of specimen is 1 type. | |
Need the space: | Front and back 0.4m,left and right 1.5m,head 1.5m | |
Power: | (220-15%～220 10%)VAC 50HZ 0.1KW | |
