Detailed Product Description
| Test Precision: | 1g | Dart Weight: | Mode A 30g; Mode B 260g |
| Dart Size: | Mode A Φ38mm; Mode B Φ50mm | Weights: | 5g, 15g, 30g, 45g, 80g, 90g, 8pcs For Each |
| Size Of Weights: | Mode A Φ30mm; Mode B Φ45mm | Impact Height: | Mode A 66cm; Mode B 150cm |
1g Test Precision Free Falling Dart Impact Plastic Testing Equipment For Plastic Flim
Introduction:
The machine is suitable for plastic film or sheet do the Free Falling Dart Impact Test under certain height
,measure 50% plastic film or sheet sample breakage when the impact of the mass and energy.
Working Principle
The dart freely falls and impact test sample; measure the weight needed to damage 50% of the number
of samples to evaluate impact resistance.
Features
1. LCD display test data.
2. Easy operation, auto process data.
3. Pneumatic clips.
4. Auto clip and release dart.
5. Built-in printer, can print report.
6. Two test modes: Mode A and Mode B.
Configuration
Falling Dart Impact Tester, clips, weights, power cable
User provide: compressed air
Specifications:
Test mode | Mode A, Mode B, optional |
Test range | Mode A 50~2000g; Mode B 300~2000g |
Test precision | 1g |
Dart weight | Mode A 30g; Mode B 260g |
Dart size | Mode A Φ38mm; Mode B Φ50mm |
Weights | 5g, 15g, 30g, 45g, 80g, 90g, 8pcs for each |
Size of weights | Mode A Φ30mm; Mode B Φ45mm |
Impact height | Mode A 66cm; Mode B 150cm |
Size of clips | outer Φ150mm, inner Φ125mm |
Sample size | 180×180mm |
Gas source | compressed air, 0.6~0.8Mpa |
Gas port | Φ8mm gas pipe |
Instrument size | 62×40×121/204cm |
